Product Name Bronze Wheel Valve
Item No 110
Test Pressure Hyraulic | 20kg/cm2g (300Psig)
Dimensions
| Inches | mm | A | B | C |
|---|---|---|---|---|
| 1/4 | 8 | 33 | 60 | 34 |
| 3/8 | 10 | 37 | 60 | 38 |
| 1/2 | 15 | 45 | 70 | 50 |
| 3/4 | 20 | 53 | 85 | 57 |
| 1 | 25 | 57 | 93 | 62 |
| 1¼ | 32 | 71 | 109 | 76 |
| 1½ | 40 | 80 | 117 | 80 |
| 2 | 50 | 86 | 137 | 86 |
| 2½ | 65 | 107 | 154 | 120 |
| 3 | 80 | 123 | 184 | 130 |
| 4 | 100 | 159 | 224 | 160 |
Materials
| Description | Material | Specification |
|---|---|---|
| Body, Bonnet & Disc | Bronze | IS: 318 LTB2 |
| Disc Nut, Gland | Bronze | IS: 318 LTB2 |
| Gland Nut | Brass | IS:6912 FLB |
| Stem | Brass | IS:6912 FLB |
| Handwheel | Cast Iron | IS:210 Gr. Fg-200 |
| Screw / Bolt & Washer | Mild Steel | IS:1367 |
| Gland Packing | Asbestos / Teflon | IS:4687 / PTFE |
Salient Features :
- Screwed Female ends to IS:554 / BS:21 / ISO:7
- High quality Teflon (PTFE) Gland Packing
- Medium Pattern
- Inside Screw, Rising Spindle, Screwed in Bonnet
- Sturdy Handle Wheel for smooth operation
Best For :
-outline-andi-nur-abdillah.png)
Water
Air
Steam
Oil
Gases
